ICON 2019-2026 Ram 1500/2009-2018 Dodge/Ram 1500 4WD, Front, V.S. 2.5 Series Coilover Kit, Internal Reservoir
- ICON Vehicle Dynamics
- SKU:211000
$1,539.15
7 in stock
Recommended add-ons
ICON 2019-2026 Ram 1500/2009-2018 Dodge/Ram 1500 4WD, Front, V.S. 2.5 Series Coilover Kit, Internal Reservoir
$1,539.15
- Get It Fast with Same-day Dispatch
- Free Shipping over $199
- All Reman Parts Ship for $299
1-2 day delivery for most. Expedited shipping options available at checkout.
Have questions? We’re here to help.
Call us at 1-800-347-1188 or chat with our tech support.
Product details
ICON's Vehicle Specific (V.S.) 2.5 Series coilover shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. Like all ICON shock absorbers, V.S. 2.5 Series shocks are 100% rebuildable and 100% revalveable.
- Adjustable coilovers yield .75-2.5” of front lift height on '09-'18 models or 0-1.5" of lift on '19-26 models
- Increased wheel travel and vehicle specific valving provides unrivaled ride quality across a wide range of on and off-road use
- Superior low speed control reduces body roll and increases on-road stability
- High quality ICON-engineered coil springs are guaranteed for life against sagging or breakage
- Corrosion resistant CAD plated shock body with 7/8" shaft
- Fully serviceable design allows for revalves, rebuilds, and an immeasurable service life
- Bolt-in design makes for an easy install into OEM shock location
CA Residents:
Prop 65 Warning
WARNING
This product can expose you to chemicals including arsenic, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Specifications
| Brand | ICON Vehicle Dynamics |
| UPC | 840103400495 |
| Proxy Number | 211000 |
| Shipping Width | 13.00 in |
| Shipping Length | 27.00 in |
| Shipping Depth | 7.00 in |
| Shipping Weight | 42.0000 LB |
Technical Notes
- Factory Wheels & Tires Fitment: Yes
- Recommended Aftermarket Wheels (2009-2018 Models): ICON Alloys - 17x8.5 with 4.75" Backspace / 0mm Offset
- Recommended Aftermarket Wheels (2019-UP Models): ICON Alloys - 18x9 with 5" Backspace / 0mm Offset
- Recommended Aftermarket Tires: 33" x 11.50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required)
- APPLICATION NOTE #55: Shocks are fully serviceable. Lift heights indicated are for a stock equipped vehicle.
- APPLICATION NOTE #100: Springs not rated for EcoDiesel equipped trucks
- APPLICATION NOTE #155: Requires recalibration of Advanced Driver Assistance Systems (ADAS) after install
- APPLICATION NOTE #162: Not compatible with factory air ride equipped vehicles
- APPLICATION NOTE #184: Will not fit Ram 1500 TRX or Ram 1500 RHO
- APPLICATION NOTE #650: 2019-2026 Ram 1500 Rebel will have front lift height range of 0-.75" over stock
- APPLICATION NOTE #651: Also fits 2019-2024 Ram 1500 Classic 4WD models. Lift height range is .75-2.5" over stock.
- APPLICATION NOTE #652: Will not fit 2009-2018 Ram 1500 RWD models
