ICON 2005-07 Ford F250/F350, 7" Lift, Stage 1 Suspension System
- ICON Vehicle Dynamics
- SKU:K67100
$3,004.49
On backorder - will ship upon availability
Recommended add-ons
ICON 2005-07 Ford F250/F350, 7" Lift, Stage 1 Suspension System
$3,004.49
- Get It Fast with Same-day Dispatch
- Free Shipping over $199
- All Reman Parts Ship for $299
1-2 day delivery for most. Expedited shipping options available at checkout.
Have questions? We’re here to help.
Call us at 1-800-347-1188 or chat with our tech support.
Product details
ICON’s 7” Suspension System for the 2005-2007 Ford Super Duty offers unparalleled performance and ride quality while giving the vehicle clearance for 38” Tall tires. This system comes complete with ICON 2.0 Aluminum Series Shocks, Dual Rate Coil Springs, Drop Pitman Arm, Pan Rod Bracket, Brake Line Brackets, Radius Arm Drop Down Brackets, ICON's Fabricated 6" Blocks and U-bolts. All of these components (excluding shocks) are covered by ICON’s Limited Lifetime Warranty.
- 75% increase in wheel travel
- Less body roll than stock
- 7” more travel from ride height to front bump stops
- State of the art dual-rate coil spring
- Lifetime guarantee that coil springs won’t sag
- Clears 38" Tall Tires
- No change in towing capacity
- No drive shaft modifications needed
- 100% Bolt-on system - No drilling, cutting, or welding necessary
CA Residents:
Prop 65 Warning
WARNING
This product can expose you to chemicals including arsenic, which is known to the State of California to cause cancer. For more information, go to www.P65Warnings.ca.gov.
Specifications
| Brand | ICON Vehicle Dynamics |
| UPC | 840103418841 |
| Proxy Number | 67100 |
| Shipping Width | 12.00 in |
| Shipping Length | 27.00 in |
| Shipping Depth | 6.00 in |
| Shipping Weight | 212.0000 LB |
Technical Notes
- OEM Wheels & Tires Fitment: Yes
- Recommended Aftermarket Wheels: ICON Alloys - 17x8.5" w/ 5.00” Backspace / 6mm Offset
- Recommended Aftermarket Wheels: ICON Alloys - 18x9" w/ 5.25” Backspace / 6mm Offset
- Recommended Aftermarket Wheels: ICON Alloys - 20x9" w/ 5.25” Backspace / 6mm Offset
- Recommended Aftermarket Tires: 37" x 12.50" (Larger tires may fit but fender trimming and modifications will be required.)
- APPLICATION NOTE #6: Springs Are Rated For Diesel Engines Only
- APPLICATION NOTE #21: Not Applicable On Vehicles Equipped With A Manual Transmission
- APPLICATION NOTE #28: Pinch Weld On ‘05-’10 Superduty Radius Arms May Come In Contact With Radius Arm Drop Bracket Hardware
- APPLICATION NOTE #29: 7” Systems Using A 4-Link In Place Of The Factory Radius Arms Do Not Require The Use Of Alignment Cams. Caster Can Be Adjusted By The Lower Link Arms
- APPLICATION NOTE #55: Shocks Are Fully Serviceable. Coilover Heights Indicated Are For A Stock Equipped Vehicle
- APPLICATION NOTE #56: Rear Add-A-Leaf Required For Truck To Sit Level When Using 6” Block Included In Kit
- Ships in multiple boxes
