ICON VEHICLE DYNAMICS 05-UP TACOMA 2.5 VS IR COILOVER KIT W PROCOMP 6"-700

Product Details

ICON Vehicle Dynamics V.S. 2.5 Series internal reservoir front coilover shocks are an incredible upgrade for the front end of the 2005-2023 Toyota Tacoma equipped with the Pro Comp 6” lift kit. These coilovers offer lift height adjustability, allowing fine tuning of ride height or the use of larger, more aggressive wheel and tire combinations. ICON’s Vehicle-specific shock length and valving along with the larger 2.5” shock body and increased piston area over stock components yield the maximum travel possible along with superior ride quality and suspension performance both on- and off-road. To better support the weight of additional accessories such as aftermarket front bumpers and winches, these coilovers include ICON engineered coil springs with an increased, 700 lbs/in spring rate, allowing for taller ride heights with increased front end weight. When paired with ICON 2.0 or 2.5 Aluminum Series rear shock absorbers vehicle control will be balanced front to rear, resulting in the best overall driving experience for your Toyota Tacoma.

  • Increased wheel travel and improved ride quality over stock
  • Vehicle specific tuned for superior shock damping and control
  • Height-adjustable coilovers with application specific length for fitment with Pro Comp 6" lift kits
  • ICON engineered coil springs with 700 lbs/in spring rate are more ideal for heavier equipped front ends
  • 6061 Aircraft grade aluminum CNC machined components
  • Corrosion resistant CAD plated shock bodies with 7/8" diameter shafts
  • FK rod end bearings for extended longevity and minimal deflection
  • Fully rebuildable and re-tunable

Technical Notes

  • TECH NOTE: Coilover length optimized for ProComp 6" lift but may also be compatible with others
  • TECH NOTE: 700lb/in spring rate only recommended for trucks with additional weight added to front end. See ICON Help Center for information.

Warranty Information

Warranty information unavailable

Compatible Make / Model

Specification

Brand ICON Vehicle Dynamics
Prop65 Warning WARNING: This product contains chemicals known to the State of California to cause cancer, and birth defects or other reproductive harm.
Technical Notes
  • TECH NOTE: Coilover length optimized for ProComp 6" lift but may also be compatible with others
  • TECH NOTE: 700lb/in spring rate only recommended for trucks with additional weight added to front end. See ICON Help Center for information.
UPC 00840103403908
Material Aluminum
Spring Rate 700
Body Diameter 2.5
Remote Reservoir NO
Adjustable Height yes
Spring Rate Type Linear
Spring Color Black
Adjustable Damping NO
Shaft Diameter 0.875
Service Parts 611019 - COILOVER HARDWARE KIT PAIR
Add-On Part 198000 - 2 PIN COILOVER SPANNER WRENCH KIT
Width 13.00 in
Length 31.00 in
Depth 7.00 in
Weight 48.0000 lb
Brand: ICON Vehicle Dynamics

ICON 2005-2023 Toyota Tacoma, 2.5 VS Coilover Kit, For Pro Comp 6” Lift, 700 lb/in Coils

58631-700-CB

8 in stock

$1,854.25 $1,668.83
Please make a selection for each of the required (*) options above before adding item to cart.
Warehouse Availability
  • CA 6
  • TX 2
  • KY 0
  • MN 0
  • WA 0
