New for ICON: 2021-'23 RAM TRX Billet UCAs with Delta Joint Pro & Rear 2.5 Hydraulic Bumpstop Kit
The RAM TRX is an amazing machine with highly capable suspension and drivetrain systems right from the factory, but ICON has identified a couple of areas where the vaunted TRX can benefit from improvement. ICON Billet Upper Control Arms provide on-vehicle adjustability to dial in alignment for any lift or suspension modifications, along with the high-angle, serviceable, and rebuildable, patented Delta Joint Pro. Our Rear Hydraulic Bumpstop Kit helps smooth suspension bottoming under hard use. Together these components help TRX owners squeeze even more performance out of an already awesome truck! 21-23 RAM TRX BILLET UCA 218561DJ 21-23 RAM TRX BILLET UCA DJ PRO KIT KEY FEATURES: CNC machined 6061 billet aluminum construction with satin anodized finish Added degree of caster from stock uca Quick, precise, on-vehicle adjustment for both caster and camber Delta Joint PRO allows maximum articulation without binding Delta Joint PRO is 100% serviceable and rebuildable FK Rod Ends at chassis pivots for strength and precision driving characteristics Built in O-ring sealed dust cover cap TECH INFO Fits RAM TRX only (does not fit other RAM models) 21-23 RAM HYDRAULIC BUMPSTOP KIT 211020 21-23 RAM TRX REAR 2.5" BUMP STOP KIT 2.25" TRAVEL KEY FEATURES: 100% bolt on 2.5 diameter bump stop design 2.5" impact extruded body hard anodized Heavy duty 1.625" shaft replaceable noise reducing striker pad IFP design 6061 billet aluminum components Velocity sensitive technology exponentially increases bottom-out resistance Vehicle specific bump stop tune provides smooth engagement and excellent ride quality TECH INFO Fits RAM TRX only (does not fit other RAM models)
New ICON Products! 2023 Ford Super Duty 4.5in Complete Suspension Systems with Gas & Diesel Specific Applications
The ICON Vehicle Dynamics presents our comprehensive array of 4.5" Complete Suspension Systems for 2023 Ford F250 & F350. ICON has optimized spring rate, ride height, and valving to the specific needs of the gas and diesel engine versions of these trucks. The Systems are arranged in 9 Stages with variations for Gas or Diesel Coil Spring or Coilver Conversion, along with two optional upgrades for our Radius Arms and/or rear leaf Expansion Packs, for a total of 78 different system configurations to meet virtually any budget or performance goal. Please read through the following information to learn more about Stages 1 through 9 and their variations, and download the provided Price & Spec Sheet and Image Collections to add the information to your own sales channels. ICON SUSPENSION SYSTEM STAGES Stage 1 through 8 Suspension Systems for Ford Super Duty feature upgraded, ICON-engineered dual rate front coil springs to provide 4.5 inches of front end lift height and superior performance over stock, without using coil spring spacers (Stage 9 is only available in Coilover Conversion variation). Basic kits include radius arm drop brackets, rear leaf spring blocks, and extended brake lines. Kits are available for either Gas or Diesel-equipped trucks to optimize performance based on the difference in engine weight. To fully realize the suspension performance potential of these trucks, ICON Coilover Conversion Systems delete the stock coil spring and shock configuration in favor of ICON 2.5 VS Series Coilovers to achieve better travel, damping, and suspension system packaging. 4-LINK FRONT SUSPENSION SYSTEMS Stages 6 and up are available with ICON's 4-Link Front Suspension System, including our heavy-duty 4-link bracket kit along with upper and lower links with on-the-vehicle adjustability. UPGRADE: COILOVER CONVERSION SYSTEMS K63172 Shown (Stage 2 Coilover Conversion) UPGRADE: RADIUS ARM SYSTEMS Stages 3 and up of our Ford Super Duty Suspension System Stages are available with our Radius Arm Kit upgrade. ICON radius arms are engineered to improve front axle alignment and allow bind-free travel and superior articulation. UPGRADE: EXPANSION PACK SYSTEMS ICON's FSD Expansion Pack is a desirable upgrade to any of the Stages. This kit modifies the stock rear leaf springs to provide suspension height without lift blocks, and with superior rear suspension performance. Suspension Stage Systems Stage 1 Suspension Systems ICON Complete Suspension Systems for Ford Super Duty begin at Stage 1, featuring ICON Dual Stage Front Coil Springs and 2.0 Series Shock Absorbers (or 2.5VS Coilovers on Coilover Conversion Systems). Rear shocks are ICON 2.0 Series Internal Reservoir Shocks. This basic kit provides 4.5" of front-end lift while improving ride and handling over stock. K64531/K64541 Shown K64541 23 FORD F250/F350 4.5" STAGE 1 SUSPENSION SYSTEM DIESEL K64541L 23 FORD F250/F350 4.5" STAGE 1 SUSPENSION SYSTEM DIESEL W/ EXPANSION PACKS K64531 23 FORD F250/F350 4.5" STAGE 1 SUSPENSION SYSTEM GAS K64531L 23 FORD F250/F350 4.5" STAGE 1 SUSPENSION SYSTEM GAS W/ EXPANSION PACKS K63171 23 FORD F250/F350 4-5.5" STAGE 1 COILOVER CONVERSION SYSTEM K63171L 23 FORD F250/F350 4-5.5" STAGE 1 COILOVER CONVERSION SYSTEM W/ EXPANSION PACKS STAGE 2 SUSPENSION SYSTEMS Stage 2 builds on Stage 1 by adding remote shock reservoirs to the front and rear shocks. The remote reservoirs add fluid capacity for increased heat dissipation. Stage 2 also adds ICON's Dual Steering Stabilizer Kit. K64532/K64542 Shown K64542 23 FORD F250/F350 4.5" STAGE 2 SUSPENSION SYSTEM DIESEL K64542L 23 FORD F250/F350 4.5" STAGE 2 SUSPENSION SYSTEM DIESEL W/ EXPANSION PACKS K64532 23 FORD F250/F350 4.5" STAGE 2 SUSPENSION SYSTEM GAS K64532L 23 FORD F250/F350 4.5" STAGE 2 SUSPENSION SYSTEM GAS W/ EXPANSION PACKS K63172 23 FORD F250/F350 4-5.5" STAGE 2 COILOVER CONVERSION SYSTEM K63172L 23 FORD F250/F350 4-5.5" STAGE 2 COILOVER CONVERSION SYSTEM W/ EXPANSION PACKS STAGE 3 SUSPENSION SYSTEMS Stage 3 steps up to ICON's 2.5 VS front shocks (for coil spring kit variants) and 2.5 VS rear shocks. Stage 3 also begins availability for ICON's Radius Arm conversion systems, which provide enhanced axle control and better ground clearance than drop brackets. K64533R/K64543R Shown K64543 23 FORD F250/F350 4.5" STAGE 3 SUSPENSION SYSTEM DIESEL K64543L 23 FORD F250/F350 4.5" STAGE 3 SUSPENSION SYSTEM DIESEL W/ EXPANSION PACKS K64543R 23 FORD F250/F350 4.5" STAGE 3 SUSPENSION SYSTEM DIESEL W/ RADIUS ARMS K64543RL 23 FORD F250/F350 4.5" STAGE 3 SUSPENSION SYS DIESEL RADIUS ARMS/EXPANSION PACKS K64533 23 FORD F250/F350 4.5" STAGE 3 SUSPENSION SYSTEM GAS K64533L 23 FORD F250/F350 4.5" STAGE 3 SUSPENSION SYSTEM GAS W/ EXPANSION PACKS K64533R 23 FORD F250/F350 4.5" STAGE 3 SUSPENSION SYSTEM GAS W/ RADIUS ARMS K64533RL 23 FORD F250/F350 4.5" STAGE 3 SUSPENSION SYSTEM GAS RADIUS ARMS/EXPANSION PACKS K63173 23 FORD F250/F350 4-5.5" STAGE 3 COILOVER CONVERSION SYSTEM K63173L 23 FORD F250/F350 4-5.5" STAGE 3 COILOVER CONVERSION SYSTEM W/ EXPANSION PACKS K63173R 23 FORD F250/F350 4-5.5" STAGE 3 COILOVER CONVERSION SYSTEM W/ RADIUS ARMS K63173RL 23 FORD F250/F350 4-5.5" STAGE 3 COILOVER CONV SYS RADIUS ARMS/EXPANSION PACKS STAGE 4 SUSPENSION SYSTEMS Stage 4 adds Remote Reservoirs to the front and rear 2.5 VS shocks (or coilovers) on all Stage variants. The big 2.5" diameter reservoirs significantly increase fluid volume to maximize heat dissipation and prolong damping performance over long sections of rough terrain. Stage 4 also adds ICON's Adjustable Track Bar kit for proper centering of the front axle. K63174L Shown K64544 23 FORD F250/F350 4.5" STAGE 4 SUSPENSION SYSTEM DIESEL K64544L 23 FORD F250/F350 4.5" STAGE 4 SUSPENSION SYSTEM DIESEL W/ EXPANSION PACKS K64544R 23 FORD F250/F350 4.5" STAGE 4 SUSPENSION SYSTEM DIESEL W/ RADIUS ARMS K64544RL 23 FORD F250/F350 4.5" STAGE 4 SUSPENSION SYS DIESEL RADIUS ARMS/EXPANSION PACKS K64534 23 FORD F250/F350 4.5" STAGE 4 SUSPENSION SYSTEM GAS K64534L 23 FORD F250/F350 4.5" STAGE 4 SUSPENSION SYSTEM GAS W/ EXPANSION PACKS K64534R 23 FORD F250/F350 4.5" STAGE 4 SUSPENSION SYSTEM GAS W/ RADIUS ARMS K64534RL 23 FORD F250/F350 4.5" STAGE 4 SUSPENSION SYSTEM GAS RADIUS ARMS/EXPANSION PACKS K63174 23 FORD F250/F350 4-5.5" STAGE 4 COILOVER CONVERSION SYSTEM K63174L 23 FORD F250/F350 4-5.5" STAGE 4 COILOVER CONVERSION SYSTEM W/ EXPANSION PACKS K63174R 23 FORD F250/F350 4-5.5" STAGE 4 COILOVER CONVERSION SYSTEM W/ RADIUS ARMS K63174RL 23 FORD F250/F350 4-5.5" STAGE 4 COILOVER CONV SYS RADIUS ARMS/EXPANSION PACKS STAGE 5 SUSPENSION SYSTEMS Stage 5 provides customization of suspension performance with the addition of ICON's Compression Damping Control Valve system on all four shocks. CDCV provides ten levels of manually adjustable compression damping to optimize performance for any on- or off-road conditions. Stage 5 also upgrades steering performance with ICON's Centerline Steering Stabilizer kit. K64535RL/K64545RL Shown K64545 23 FORD F250/F350 4.5" STAGE 5 SUSPENSION SYSTEM DIESEL K64545L 23 FORD F250/F350 4.5" STAGE 5 SUSPENSION SYSTEM DIESEL W/ EXPANSION PACKS K64545R 23 FORD F250/F350 4.5" STAGE 5 SUSPENSION SYSTEM DIESEL W/ RADIUS ARMS K64545RL 23 FORD F250/F350 4.5" STAGE 5 SUSPENSION SYS DIESEL RADIUS ARMS/EXPANSION PACKS K64535 23 FORD F250/F350 4.5" STAGE 5 SUSPENSION SYSTEM GAS K64535L 23 FORD F250/F350 4.5" STAGE 5 SUSPENSION SYSTEM GAS W/ EXPANSION PACKS K64535R 23 FORD F250/F350 4.5" STAGE 5 SUSPENSION SYSTEM GAS W/ RADIUS ARMS K64535RL 23 FORD F250/F350 4.5" STAGE 5 SUSPENSION SYSTEM GAS RADIUS ARMS/EXPANSION PACKS K63175 23 FORD F250/F350 4-5.5" STAGE 5 COILOVER CONVERSION SYSTEM K63175L 23 FORD F250/F350 4-5.5" STAGE 5 COILOVER CONVERSION SYSTEM W/ EXPANSION PACKS K63175R 23 FORD F250/F350 4-5.5" STAGE 5 COILOVER CONVERSION SYSTEM W/ RADIUS ARMS K63175RL 23 FORD F250/F350 4-5.5" STAGE 5 COILOVER CONV SYS RADIUS ARMS/EXPANSION PACKS STAGE 6 SUSPENSION SYSTEMS Stage 6 introduces ICON's Front 4-Link Suspension system for ultimate axle control and suspension performance (Radius Arm variants not available for Stage 6). Stage 6 also includes ICON 2.5 VS Series front and rear shocks with remote reservoirs, and ICON's dual opposing steering stabilizer system. K64536/K64546 Shown K64546 23 FORD F250/F350 4.5" STAGE 6 SUSPENSION SYSTEM DIESEL K64546L 23 FORD F250/F350 4.5" STAGE 6 SUSPENSION SYSTEM DIESEL W/ EXPANSION PACKS K64536 23 FORD F250/F350 4.5" STAGE 6 SUSPENSION SYSTEM GAS K64536L 23 FORD F250/F350 4.5" STAGE 6 SUSPENSION SYSTEM GAS W/ EXPANSION PACKS K63176 23 FORD F250/F350 4-5.5" STAGE 6 COILOVER CONVERSION SYSTEM K63176L 23 FORD F250/F350 4-5.5" STAGE 6 COILOVER CONVERSION SYSTEM W/ EXPANSION PACKS STAGE 7 SUSPENSION SYSTEMS Stage 7 builds on Stage 6 with CDCV adjustable valving and adds a secondary 2.5 VS Front Shock with Remote Reservoir, for even more damping performance, fluid capacity and heat dissipation. Unlike Stage 6, Stage 7 is available in both coil spring and coilover conversion variations. K63177R Shown K64547 23 FORD F250/F350 4.5" STAGE 7 SUSPENSION SYSTEM DIESEL K64547L 23 FORD F250/F350 4.5" STAGE 7 SUSPENSION SYSTEM DIESEL W/ EXPANSION PACKS K64537 23 FORD F250/F350 4.5" STAGE 7 SUSPENSION SYSTEM GAS K64537L 23 FORD F250/F350 4.5" STAGE 7 SUSPENSION SYSTEM GAS W/ EXPANSION PACKS K63177 23 FORD F250/F350 4-5.5" STAGE 7 COILOVER CONVERSION SYSTEM K63177L 23 FORD F250/F350 4-5.5" STAGE 7 COILOVER CONVERSION SYSTEM W/ EXPANSION PACKS K63177R 23 FORD F250/F350 4-5.5" STAGE 7 COILOVER CONVERSION SYSTEM W/ RADIUS ARMS K63177RL 23 FORD F250/F350 4-5.5" STAGE 7 COILOVER CONVER SYS RADIUS ARMS/EXPANSION PACKS STAGE 8 SUSPENSION SYSTEMS Stage 8 utilizes ICON's proprietary Compression Damping Electronic Valve (CDEV) technology powered by ICON Intelligent Control (ICC). This system provides full electronic adjustability for ride quality as well as reactive, intelligent adjustment on-the-fly as the system reacts to inertia, terrain, and speed in microseconds. Standard Stage 8 comes with our 4-link Front Suspension system. Radius Arm kit, Coilover conversion, and Rear Leaf Expansion Pack are all optional, making Stage 8 completely configurable to your truck's individual needs. K64538RL/K64548RL Shown K64548 23 FORD F250/F350 4.5" STAGE 8 SUSPENSION SYSTEM DIESEL K64548L 23 FORD F250/F350 4.5" STAGE 8 SUSPENSION SYSTEM DIESEL W/ EXPANSION PACKS K64548R 23 FORD F250/F350 4.5" STAGE 8 SUSPENSION SYSTEM DIESEL W/ RADIUS ARMS K64548RL 23 FORD F250/F350 4.5" STAGE 8 SUSPENSION SYS DIESEL RADIUS ARMS/EXPANSION PACKS K64538 23 FORD F250/F350 4.5" STAGE 8 SUSPENSION SYSTEM GAS K64538L 23 FORD F250/F350 4.5" STAGE 8 SUSPENSION SYSTEM GAS W/ EXPANSION PACK K64538R 23 FORD F250/F350 4.5" STAGE 8 SUSPENSION SYSTEM GAS W/ RADIUS ARMS K64538RL 23 FORD F250/F350 4.5" STAGE 8 SUSPENSION SYSTEM GAS RADIUS ARMS/EXPANSION PACKS K63178 23 FORD F250/F350 4-5.5" STAGE 8 COILOVER CONVERSION SYSTEM K63178L 23 FORD F250/F350 4-5.5" STAGE 8 COILOVER CONVERSION SYSTEM W/ EXPANSION PACKS K63178R 23 FORD F250/F350 4-5.5" STAGE 8 COILOVER CONVERSION SYSTEM W/ RADIUS ARMS K63178RL 23 FORD F250/F350 4-5.5" STAGE 8 COILOVER CONV SYS RADIUS ARMS/EXPANSION PACKS STAGE 9 SUSPENSION SYSTEMS Stage 9 takes our top suspension system one step further with an additional pair of 2.5 VS CDEV secondary shocks in the front. The result is the pinnacle in long-haul suspension performance with double the front damping performance, fluid capacity, and heat dissipation, all utilizing the on-the-fly adjustability of ICON's proprietary CDEV system. As this system represents the ultimate in Super Duty suspension performance, Stage 9 is only available in our Coilover Conversion variations. K63179RL Shown K63179 23 FORD F250/F350 4-5.5" STAGE 9 COILOVER CONVERSION SYSTEM K63179L 23 FORD F250/F350 4-5.5" STAGE 9 COILOVER CONVERSION SYSTEM W/ EXPANSION PACKS K63179R 23 FORD F250/F350 4-5.5" STAGE 9 COILOVER CONVERSION SYSTEM W/ RADIUS ARMS K63179RL 23 FORD F250/F350 4-5.5" STAGE 9 COILOVER CONV SYS RADIUS ARMS/EXPANSION PACKS Call us today for more information or to place an order!
New ICON Product: 2005-23 Toyota Tacoma Lower Control Arm Kit
The ICON Vehicle Dynamics 2005-2023 Toyota Tacoma Lower Control Arm Kit is designed to be the ultimate stock-width replacement control arm upgrade. Their fully welded, boxed, CNC laser cut and brake-formed steel plate construction is internally braced with multiple ribs to offer significantly improved strength over the stock Tacoma LCAs. Featuring a high ground clearance design, specially angled plates also allow the arms to easily slide over larger obstacles out on the trail. CNC machined forged steel ball joint housings maintain the highest possible ground clearance while also ensuring strength and appropriate CV boot clearance on 4WD Tacoma models. Rather than using traditional top-mounted coilover mounting tabs, these LCAs utilize recessed coilover mounts, further increasing strength and provide race-inspired styling. Their incorporated secondary shock mounting tabs tie seamlessly into the ICON S2 Secondary Shock System for a fully bolt-on installation of multiple secondary shock options to effectively double the shock-damping ability of the front suspension and improve off-road performance. To make these arms as much at home on the street as they are on the trail, the lower ball joints are of a metal on metal and greaseable design to avoid the short service life and noises typically associated with uniballs while also being able to withstand the abuses of aggressive off-road use. The inner pivot bushings are bonded polyurethane to the outer sleeve and unbonded inner sleeve to minimize deflection and improve handling characteristics while allowing unhindered suspension movement though the entire travel range. Additionally, these specialty bushings do not require any greasing or other maintenance throughout their service life. With features like these, the ICON 2005-2023 Toyota Tacoma Lower Control Arm Kit would make an incredible addition to round out your Tacoma’s suspension system. 54300 05-23 TACOMA LOWER CONTROL ARM HARDWARE KITS (Order Separately): 54301 16-23 TACOMA LCA HARDWARE KIT 05-15 TACOMA LCA HARDWARE KIT KEY FEATURES: High clearance, stock width design Fully welded boxed steel construction with internal ribs for maximum strength CNC laser cut and brake formed steel plate ICON secondary shock compatibility with ICON S2 Shock Hoops (sold separately) Recessed coilover mounting points Pocketed lower plates allow drainage and easy access to coilover mounting hardware Angled front plates and relocated steering stops help arms slide over obstacles and prevent trail hang ups CNC machined forged ball joint housings ensure strength and CV boot clearance Metal on metal, greaseable lower ball joints for longevity and noise free operation Maintenance free bonded polyurethane bushings Semi-gloss black powder coat finish for corrosion resistance Fabricated components covered by ICON’s Limited Lifetime Warranty TECH NOTES: OEM Wheels & Tires Fitment: Yes Recommended Aftermarket Wheels: ICON Alloys - 17x8.5 with 4.75” Backspace / 0mm Offset Recommended Aftermarket Wheels: ICON Alloys - 18x9 with 5.00” Backspace / 0mm Offset Recommended Aftermarket Wheels: ICON Alloys - 20x9 with 5.00” Backspace / 0mm Offset Recommended Aftermarket Tires: 33" x 11.50" (Larger tires may fit but fender trimming and modifications will be required.) APPLICATION NOTE #167: 2005-2015 Tacoma also requires part # 43502 APPLICATION NOTE #168: 2016-2023 Tacoma also requires part # 4350 TECH NOTE: Fits 2005-2015 4WD and PreRunner and 2016-2023 2WD/4WD Toyota Tacoma models TECH NOTE: Will not fit 2005-2015 2WD 5-Lug Toyota Tacoma models
New ICON Product: 2021-Up (Gen 3) Ford Raptor Billet Upper Control Arms with Delta Joint PRO
This ICON billet aluminum upper control arm kit is designed to improve the overall performance of the new Gen3 Ford Raptor with corrected front-end geometry, adjustable camber and caster, and improved suspension component clearance. These are constructed of CNC machined 6061 billet aluminum merging light weight with high strength properties. Replacing the OE ball joint with the ICON Delta Joint PRO allows for full bump and droop travel of the front suspension while eliminating bind. FK Rod End 7/8” heim joints provide precise and smooth function throughout the range of travel while ICON’s signature double adjuster sleeve allows for on-vehicle camber and caster adjustment. Included with all components and hardware necessary for a complete install, these billet UCAs are the perfect upgrade for the 2021-2023 Ford Raptor. Delta Joint PRO is ICON's innovative new suspension articulation joint which combines the durability and longevity of factory-style ball joints with performance and strength that exceeds traditional motorsports-style ball joints. Strength and durability are improved by using a larger ball with 56% more bearing surface than our standard Delta Joint, along with improved lubrication sealing. But improved performance is at the heart of the Delta Joint PRO, with a full 90 degrees of articulation, from one extreme to the other. This represents a 14% improvement in range of motion, over the highly capable original Delta Joint, allowing for maximum bind-free suspension movement through the complete range of travel. The Delta Joint PRO is built to take the abuse, with a chromoly ball and shaft that has a bearing surface hardened to Rockwell C 55. The replaceable races are made of graphite-impregnated sintered metal, machined to the finest tolerance to provide a flawless, metal-to-metal bearing interface. We also redesigned the lubrication system, with lubricant channels that distribute grease more efficiently without extending past the bearing seal. 98564DJ 21-23 RAPTOR BILLET UCA DJ PRO KIT KEY FEATURES: CNC machined 6061 billet aluminum construction with satin anodized finish Corrects suspension geometry and allows for proper wheel alignment on Gen3 Raptors with up to 3” of front lift Quick, precise, on-vehicle adjustment for both caster and camber Patented Delta Joint PRO (U.S. Pat. 10,731,700) allows maximum articulation without binding Delta Joint PRO is 100% serviceable and rebuildable FK Rod Ends at chassis pivots for strength and precision driving characteristics Built in O-ring sealed dust cover cap TECH INFO EM Wheels & Tires Fitment: Yes Recommended Aftermarket Wheels: ICON Alloys - 17" x 8.5" with 5" Backspace/6mm Offset Recommended Aftermarket Wheels: ICON Alloys - 18" x 9" with 5.25" Backspace/6mm Offset Recommended Aftermarket Wheels: ICON Alloys - 20" x 9" with 5.625" Backspace/16mm Offset Recommended Aftermarket Tires: 35X12.50" (Larger Tires May Fit but Fender Trimming and Modifications will be Required) Ride height sensor calibration recommended
The New 4th Gen Tacoma is Here!
TACOMA MEETS ICON INNOVATION As devoted Toyota Tacoma enthusiasts, we've been eagerly anticipating the arrival of the 2024 model, and it's finally here! Don't hesitate to join our notification list now to stay ahead of the curve. JOIN THE TACOMA LIST TACOMA NEW PRODUCTS Go behind the scenes with ICON Engineering as they discuss ICON's mastery of complete performance suspension systems, shock absorbers, and wheels to be released for the new Tacoma very soon!
